A 3D MODEL DESIGN OF AN ATMOSPHERIC AIR FILTER
This system is designed to monitor and purify atmospheric air, releasing purer and refined air back into the environment.
It begins with Section One (the black block and white tube) which analyzes air components and ensures stability and cleanliness. If an imbalance in the components or a pollutant is detected, the red bulb illumines and signals The Suction Section to begin drawing in atmospheric air.
After a while, the Release Section (the cylinder at the back) is activated and the Expansion Valve converts stored liquefied air into vapour and releases to the atmosphere.
The air drawn by The Suction Section is liquefied by a compressor and condenser, then enters the Brown Cylinder where the air components are separated and taken to their respective container (represented as the coloured cylinders). The different components are channeled to their respective filter system (the coloured semi cylinders) where each component of air is filtered. All components then travel to the Release Section where they are stored as a liquid until signaled to be released into the atmosphere.
This system helps to ensure a balance of air components, eliminating harmful substances and ultimately reducing climate change.
